What material is the label attached to?
What is the surface and shape of the bearing?
How long does it take to paste?
Is it a permanent paste or need to be uncovered?
Used indoors or outdoors? How about high and low temperature and humidity?
Manual labeling or automatic labeling?
The material, color, size and shape of the label?
Is there any variable information to print?
Is information generated by laser printing, thermal transfer printing or laser etching?
Is there any legal restriction?
Are there any other special performance requirements?
| Product name | Product description | application |
3M3690 3M3698 |
The durable coating is heat transfer printing ethylene film, which has good flexibility, high toughness adhesive layer has high adhesion strength to various surfaces, and the short-term temperature resistance reaches 120 ℃ | The adhesive resistance of the small diameter surface is excellent, and the adhesive effect is good on the spray paint surface, low energy plastic surface and rough surface. In most cases, the label will be destroyed once it is torn. You can heat transfer to print barcode |
3M7871 3M7872 3M7879 |
The high retention adhesive layer has high adhesion strength and anti bonding decay ability to various surfaces, and the short-term temperature resistance is 176 ℃ | The thickened adhesive layer is very suitable for pasted powder coating, low energy plastic surface, oil-stained metal and textured surface. It has good corrosion resistance and chemical corrosion resistance, and can heat transfer to print barcode |
3M7860 3M7818EH 3M7875 3M7840TL |
The high stability adhesive layer provides high bonding strength and anti bonding decay ability, and short-term temperature resistance is 176 ℃ | It provides a stable and lasting adhesive strength for various surfaces including high surface energy plastics and metals, and has strong impermeability. It can adapt to various printing technologies including heat transfer and laser printing |
3M FP016903 |
The high stability adhesive layer can be permanently pasted and cleaned and stripped | After one year of paste, it can still be removed from most surfaces, which is very suitable for the label of precision electronic parts such as die cutting mask, hard disk and other precise electronic parts which need outdoor performance and detachable |
3m7380 7381 hoarse silver anti-counterfeiting |
The high strength adhesive layer has stronger initial adhesion to low surface energy plastics and short-term temperature resistance of 120 ℃ | The tear off label shows the obvious opening indication - void (invalid tear), which is very suitable for the safety quota label and inspection mark; The adhesive layer has excellent anti - viscosity resistance and decay |
Fragile paper |
The fracture strength of the fabric is far lower than the adhesive adhesive adhesive, which has the characteristics that it can not be completely peeled and reused after bonding | After the processing of the fragile paper adhesive surface material through printing and die cutting, it can be made into fragile label or fragile paste, also known as commodity fragile quality assurance paste. It is mainly used in some unconventional commodity identification methods which are difficult to guarantee accurately by regular quality assurance |
3M3922DL |
It provides super high temperature resistance and excellent solvent resistance. It has high bonding strength on various surfaces | It is recommended to be used in the production of printing labels in transfer applications |
3M7847 |
Excellent resistance to high temperature, chemical and environmental erosion. The two-layer film structure provides excellent durability. It has excellent adhesive force for low surface plastics, and the surface material which is easy to break has the ability of tearing on some bottom materials | It is suitable for heat transfer printing in electronic and automotive industries, and difficult to stick to (low surface energy and oil pollution) |
XF584 M-8521 |
The PI film is printed by heat transfer of durable coating. The high temperature resistant adhesive layer can be permanently pasted and cleaned and stripped, and the temperature resistance is 260 ℃ for a short time | The adhesive layer has strong shear force at high temperature and low gas volatilization. It is usually used in PCB. Can print two-dimensional barcode |
What is the material of the bearing?
Is the material thin or thick, flexible or hard and strong?
What is the surface and shape of the material?
What environment will the adhesive tape is applied (temperature and humidity changes, sunlight, water, oil or solvent)?
What about the stress of adhesive tape after sticking: shear force, peeling force, positive pulling force and cracking force?
Does the color of the adhesive tape meet the appearance requirements of the product?
Does the thickness of adhesive tape meet the requirements of gap filling and sealing?
| Product name | Product description | Application characteristics |
3m467MP, 200MP without material 3m468MP, 200MP # without material |
The high stability adhesive layer without base material provides high adhesive strength and resistance to adhesive decay, and short time temperature resistance is 176 ℃ | The adhesive tape provides stable and durable adhesive strength to various surfaces including high surface energy plastics and metals, and the adhesive layer has strong impermeability |
3m9495MP 200MP with substrate |
It is made of transparent PET double-sided coated acrylic tape, the color of the tape is transparent, the specification is 1372mm * 55m * 0.14mm, and it will not wrinkle under high humidity conditions; The long-term temperature resistance is 121 ℃ and the short-term temperature resistance is 149 ℃ | It has good dimensional stability, thermal stability, chemical stability, good initial viscosity and holding viscosity, easy die-cutting processing, and good adhesion to plastics, rubber and nameplates; It can be applied to a wider temperature range and harsh environment |
3m9672LE 300LSE without substrate 3m9495MP 300LSE with substrate |
The high adhesion adhesive layer without base material provides high initial bond strength and resistance to bond decay, with short time temperature resistance of 150 ℃ | The adhesive tape provides a stable and durable adhesive strength to various surfaces including low surface energy plastics and spraying treatment, and the adhesive layer has strong impermeability |
3M4920 3M4930 3M4950 3M9460 |
3M super high adhesive strength acrylic double sided tape (VHb), with thickness of 0.05 ~ 1.10 mm and temperature resistance of 260 ℃ | The tape also has strong shear force at high temperature, good weather resistance and solvent resistance, and low gas volatilization |
GERGONNE3976 with substrate TESA 4965 with substrate |
The high retention adhesive layer based on pet tape has high adhesive strength and resistance to adhesive decay on various surfaces, and the temperature resistance can reach 176 ℃ in a short time | This tape is very suitable for sticking powder coating, low energy plastic surface, oil contaminated metal and textured surface, good corrosion resistance and chemical erosion ability |
NAME DSMS |
The two sides of pet tape base are different adhesive double-sided tape, one side is propionic acid base, the other side is silica gel base | This adhesive tape is suitable for sticking on one side of silicone rubber material and on the other side of metal and high-energy plastic surface, such as keys, sealing rings and other electronic components |
If there is moisture, oil and release agent on the bearing paste, the adhesive force of the material will be reduced, and it should be cleaned before construction.
When self-adhesive labels and tapes are used for sticking rough surfaces and curved surfaces, it is recommended to conduct tests first to determine the materials and substrates to be used.
When pressure is applied during bonding, there will be sufficient bonding effect.
As ultraviolet radiation may degrade the adhesive, the adhesive will be affected by temperature and humidity changes, so please pay more attention to the use and storage of adhesive labels and tapes, and the adhesive stress will stabilize after 24 hours.
